 Specifications - Gasket |
*Use : GND, Adhesion location : MOLDING,SHIELD CAN FPCB |
|
|
| NO. |
Thickness(Total) |
Specifications |
Adhesion Materials |
Color |
| 1 |
0.05T |
Woven |
Acrylic |
Gold |
| 2 |
0.07T |
Woven |
Acrylic |
Gold |
| 3 |
0.05T |
Woven |
Acrylic |
Dark Gray |
| 4 |
0.11T |
Woven |
Acrylic |
Dark Gray |
|
| |
| Specifications - Pad |
|
|
|
| NO. |
Use |
Adhesion
Location |
Material
Specifications |
Color |
Features |
| 1 |
PAD LCD |
LCD |
SRL-TF |
Black |
No PET, highest compression rate 2 |
| 2 |
Camera |
Window |
SRP |
White |
standard product, cheap price, good compression rate |
| 3 |
Camera
Cushion |
Front |
SRP-DC |
Black |
SLICON adhesion , good compression |
| 4 |
Window
Protection |
Vibrator |
TK |
Black |
Good energy absorption, Vibration prevention |
| 5 |
Shock
Absorption |
Speaker |
WS |
Black |
Good adhesion |
| 6 |
Others |
Mic |
SRS |
Black |
Good compression rate |
| 7 |
|
Rear |
PSR |
Black |
|
| 8 |
|
Camera |
HRC |
Black |
|
| 9 |
|
Others |
... |
|
|
|
| |
| Specifications - Protection Vinyl |
|
|
|
| NO. |
Use |
Adhesion
Location |
Thickness
(Total) |
Material
Specifications |
Adhesion
Materials |
Color |
Release Paper
Specifications |
| 1 |
Window
Protection |
Front Window |
0.18 |
PET |
Silicon |
Transparent |
PET fluorine |
| 2 |
Window
Protection |
Front Window |
0.13 |
PP |
Silicon |
Transparent |
PET fluorine |
| 3 |
Window
Protection |
Front Window |
0.08 |
Integrated film |
Acrylic |
Transparent |
YP+PET
single layer
Silicon |
| 4 |
Window
Protection |
Front Window |
0.09 |
PET |
Silicon |
Transparent |
Non-processed
PET 0.025T |
| 5 |
Window
Protection |
Front Window |
0.85 |
PET |
Silicon |
Transparent |
Non-processed
PET 0.075T |
| 6 |
Window
Protection |
Front Window |
0.85 |
PET |
Silicon |
Blue |
Non-processed
PET 0.075T |
| 7 |
Window
Protection |
Front Window |
0.05 |
PET |
Acrylic |
Transparent |
CP Duplex
Silicon |
| 8 |
Window
Protection |
Front Window |
0.16 |
PET |
Silicon |
Transparent |
PET+
Non-processed |
|
| |
| Specifications - Molding Protection |
*Use : MOLDING surface protection, Adhesion location : UPPER COVER |
|
|
| NO. |
Thickness(Total) |
Specifications |
Adhesion Materials |
Color |
| 1 |
0.15T |
PET |
Acrylic |
Transparent |
|
| |
| Specifications - Insulator |
*Use : Parts short prevention, Adhesion location : PCB parts shor |
|
|
| NO. |
Thickness(Total) |
Adhesion Materials |
Color |
| 1 |
0.05T |
Acrylic |
Blue |
| 2 |
0.07T |
Silicon |
Amber |
| 3 |
0.2T |
Acrylic |
Black |
|
| |
| Specifications - Side Key Fix |
*Use : SIDE KEY fix, Adhesion location : FRONT |
|
|
| NO. |
Thickness(Total) |
Specifications |
Adhesion Materials |
Color |
| 1 |
0.08T |
PET |
Silicon |
Blue |
| 2 |
0.08T |
PET |
Silicon |
Green |
| 3 |
0.07T |
PET 0.025T |
Silicon |
Green |
| 4 |
0.09T |
PET 0.025T |
Silicon |
Transparent |
|
| |
| Specifications - Double-Sided Tape |
|
|
|
| NO. |
Use |
Adhesion Location |
Thickness
(Total) |
Specifications |
Adhesion
Materials |
Color |
| 1 |
Window Adhesion |
Front Upper Layer |
0.3T |
PET 0.177T |
Acrylic |
Black |
| 2 |
Mic ,Speak |
Earphon Jack |
0.05T |
PET 0.012T |
Silicon |
Transparent |
| 3 |
Window Adhesion |
Front Upper Layer |
0.15T |
PET 0.019T |
Silicon |
Transparent |
| 4 |
Common Use |
Rear |
0.05T |
PET 0.012T |
Acryl |
Transparent |
| 5 |
Common Use |
Folder |
0.1T |
PET 0.012T |
Acryl |
Transparent |
| 6 |
Common Use |
Front |
0.15T |
PET 0.012T |
Acryl |
Semi-
Transparent |
| 7 |
Window Adhesion |
Front Upper Layer |
0.15T |
PET 0.012T |
Acryl |
Black |
| 8 |
Camera Window
Adhesion |
Camera |
0.2T |
PET 0.012T |
Acrylic |
Semi-
Transparent |
| 9 |
Common use |
Folder |
0.1T |
PET 0.06T |
Acrylic |
Transparent |
| 10 |
Motor |
Motor |
0.05T |
PET 0.025T |
Acrylic |
Blue |
| 11 |
Mic Speak |
FilterI Speak |
0.05T |
PET 0.03T |
Acrylic |
Transparent |
| 12 |
Window Adhesion |
Common Use |
0.1T |
PET 0.08T |
Acryl |
Transparent |
| 13 |
Window Adhesion |
Common Use |
0.05T |
PET 0.03T |
Acryl |
Transparent |
| 14 |
Window Adhesion |
Upper, Lower,
Front Upper Layer |
0.2T |
PET 0.15T |
Acryl |
Black |
| 15 |
Window Adhesion |
Upper, Lower,
Front Upper Layer |
0.2T |
PET 0.14T |
Acryl |
Black |
|
|
|
